UGP100086

Pneumatic manifold G1-MO 1xNO-O/C 1xNO-LU 1xNC, modulating with quick open/close function for double acting actuator

Technical features

• Suitable for double acting (DA) actuator
• Fail safe lock-up function (1x NC, power/signal loss)
• Modulating MO (1x NC) function
• Oopen/close O/C (1x NC) function
• Lock-up LU (1x NC) function
• SIL2 certified according to IEC 61508
• Operation pressure 0…10 bar (0…145psi)
• Operation temperature -25°C -13°F / +70°C +158°F
• Supplied medium air, filtered non-lubricated and dry
• Equipped with prepared lock-up valve connection (P/P1)
• ATEX implementation suitable

Function

• Modulating (MO) and open/close (O/C)

Configuration

• 1x normally closed (NC), for modulating
• 1x normally closed (NC) for open/close
